PCB Tolerances

Welcome to PCB Price Pro!

Our Manufacturer adheres to strict tolerance guidelines to ensure the best results during the manufacturing of your printed circuit boards.

Supported PC Board Specs:

Min size: 1.967 in. X 1.967 in.
Max size: 19.67 in. X 19.67 in.
Min thickness: 4 mil
Max thickness: 240 mil
Layer Count: Up to 24
Finishes: HASL, ENIG, Silver, SMOBC/HAL,All Finishes acceptable
Markings: Silkscreen, Solder Mask (preferred)…not required on PCB, assembly drawings can work as a replacement to silk screen
Material: Rigid, Rogers 4000, Flex, Rigid Flex, Metal Clad, Other
Copper Thickness: < 2 oz.

Call for other options

Contact Us for more information!

Printed Circuit Board Assembly Referral Available Upon Request
